UNI-T UTi260B Pro Series Handheld Professional Thermal Imager

₦450,000

UNI-T UTi260B Pro Series Handheld Professional Thermal Imager, an advanced diagnostic camera used extensively across mechanical, electrical, and HVAC troubleshooting fields. Applications: Electrical Troubleshooting: Safely scan breaker panels, transformers, busbars, and loose terminals to isolate abnormal resistance and dangerous hot spots. HVAC and Plumbing Inspections: Trace underfloor heating arrays, pinpoint hidden water leaks inside walls, or detect structural air insulation gaps. Electronics and PCB Engineering: Locate short circuits, overheating microchips, or faulty capacitors on exposed electronic circuit assemblies.

Specifications

Infrared Resolution:

256 x 192 pixel sensor layout yielding 49,152 active monitoring data points.

Temperature Spectrum Bounds:

Reads standard environments from -20°C up to 550°C effortlessly.

Thermal Sensitivity (NETD):

≤50mK to 60mK, catching tiny fractional variations in surface radiation levels.

On-Board Display Screen:

Outfitted with a bright 2.8-inch TFT LCD window (320 x 240 pixel base layout).

Extended Operational Battery Life:

Standard built-in rechargeable Li-ion module supporting roughly 6 hours of continuous structural testing runs.

Key Features

Dual-Lens Imaging Technology: Houses both an infrared sensor and a standard visual-light camera, enabling operators to blend views through thermal fusion or picture-in-picture display modes.

Configurable Target Measurement Points: Allows users to track automated structural center-points alongside three custom region-of-interest analysis parameters simultaneously.

Rugged Heavy-Duty Build Quality: Specifically built with an IP65 dust and water-resistance rating and drop-proofed up to 2 meters for intense field work environments.

Real-Time Data Transmission: Links directly to proprietary PC software via a fast Type-C connection for real-time video projection and comprehensive diagnostics tracking.
